Bell L Series
Category:
4G LTE BBU
Description
Highlights:
● Based on advanced SOC platform to provide high performance
● 3 cells, up to 3600 online users or 1800 active users totally
● FDD peak rate (up to): DL 391Mbps, UL 75Mbps @ 20MHz
● Plug&play with SON capabilities
● Embedded core network as optional
● OPEX reduction thanks to lower power consumption
|
Model |
4G LTE BBU |
|
Standard |
LTE-A TDD/FDD, 3GPP R15 |
|
Capacity |
3cells (S111), up to 3600 online users or 1800 active users totally |
|
Bandwidth |
1.4MHz/3MHz/5MHz/10MHz/15MHz/20MHz |
|
Throughput |
2T4R/4T4R , 64QAM,20MHz bandwidth 2T4R: DL 195Mbps ; UL 75Mbps 4T4R: DL 391Mbps ; UL 75Mbps |
|
Function |
DRX, VoLTE, IPv6, CSFB, CA, DL 4 layers, UL 2 layers* |
|
Modulation |
QPSK, 16QAM, 64QAM, 256QAM |
|
Backhaul |
1 optical (1G SFP+) and 1 RJ-45 Ethernet interface (1 GE) |
|
Fronthaul |
3 x optical (CPRI) (10Gbps) |
|
Dimension |
1 U high * 19 inches wide |
|
Power supply |
AC 220V (AC 140V~300V/45Hz~65Hz) DC - 48V (DC -40V~-57V) |
|
Power consumption |
< 60W |
